Black Ostrich: Web Application Scanning with String Solvers

By Benjamin Eriksson, Amanda Stjerna,
Riccardo De Masellis, Philipp Rümmer, Andrei Sabelfeld

In ACM Conference on Computer and Communications Security (CCS), Copenhagen, Denmark November 2023.

Securing web applications remains a pressing challenge. Unfortunately, the state of the art in web crawling and security scanning still falls short of deep crawling. A major roadblock is the crawlers’ limited ability to pass input validation checks when web applications require data of a certain format, such as email, phone number, or zip code. This paper develops Black Ostrich, a principled approach to deep web crawling and scanning. The key idea is to equip web crawling with string constraint solving capabilities to dynamically infer suitable inputs from regular expression patterns in web applications and thereby pass input validation checks. To enable this use of constraint solvers, we develop new automata-based techniques to process JavaScript regular expressions. We implement our approach extending and combining the Ostrich constraint solver with the Black Widow web crawler. We evaluate Black Ostrich on a set of 8,820 unique validation patterns gathered from over 21,667,978 forms from a combination of the July 2021 Common Crawl and Tranco top 100K. For these forms and reconstructions of input elements corresponding to the patterns, we demonstrate that Black Ostrich achieves a 99% coverage of the form validations compared to an average of 36% for the state-of-the-art scanners. Moreover, out of the 66,377 domains using these patterns, we solve all patterns on 66,309 (99%) while the combined efforts of the other scanners cover 52,632 (79%). We further show that our approach can boost coverage by evaluating it on three open-source applications. Our empirical studies include a study of email validation patterns, where we find that 213 (26%) out of the 825 found email validation patterns liberally admit XSS injection payloads.

Black Ostrich Paper

Download the paper Paper
Download the extended paper Extended paper

Black Ostrich Code & Data

Download the code and data Black Ostrich (34MB)


We also created the Input Validation Challenge where you can try to solve the patterns on the web.
