Concurrency

• Processes

  • Forking

• Message passing

  • Synchronization and naming conventions
  • Erlang approach

• Reacting to multiple messages

  • From the same origin as well as different sources

• More sequential constructions

  • Exceptions
  • List comprehensions
  • Lambda expressions
  • Higher-order functions

---

Processes

code

• Process is a sequential program that can send and receive messages to/from other processes.

• Each process has a mailbox (message queue)

• No shared data!

  • Each process owns all values that it has created or received from other processes
  • Isolation
  • Implementation: each process has its own heap (what are the performance implications?)
  • Different from threads

• Sending messages

  • Proc!Msg puts Msg into the mailbox of Proc (identified by process id or registered name)
  • Sending is asynchronous

• Receiving messages

  • receive X1 -> E1; X2 -> E2; ... end looks at each message from the mailbox (starting from the oldest one) and tries to match it against each of the patterns
  • The oldest message that matches any of the patterns is removed from the mailbox, and the relevant expression becomes the value of the receive statement
  • If no message matches any of the patterns, the process will be stuck waiting for a message that matches
  • Receive statement may have guards

• Spawning processes

  • Builtin function spawn() takes a function as argument and creates a new process that starts executing that function

  start() ->
       Pid = spawn(fun run/0),
       io:format("Spawned ~p~n",[Pid]).

  run() ->
   io:format("Hello!~n",[]).


  • Expression fun run/0 indicates to execute the function run which has zero arguments.
  • Function spawn returns the proceed Id (Pid) of the newly created process for future interaction with it.
  • Function self() returng the PID of the current process

Passing a value

  test1(N) ->
    P = self(),
    Pid = spawn(messages, run, [P]),
    io:format("Spawned ~p~n",[Pid]),
    io:format("Sending ~p~n",[N]),
    Pid!{msg1, N},
    receive
      {msg2, M} ->
         io:format("Received back ~p~n",[M])
    end.

  run(P) ->
    io:format("Hello!~n"),
    receive
      {msg1, N} ->
        io:format("Received ~p~n",[N]),
        io:format("Sending back ~p~n",[N+1]),
        P!{msg2, N+1}
    end.

• spawn(messages, run, [P]) is another variant of spawn(), which takes the name of the module, the name of the function, and the arguments to the function

  • The function must be exported by the module

• Functions are part of the erlang module (more here)

Mailboxes (message queues)

• Erlang has the ability to "listen" for messages from different senders

  • In which order will they be process?

  • Can we force an order?

• The semantics for a receive statement

  • A receive statement tries to find a match as early in the mailbox as it can

    receive
       msg3 -> 42
    end




  • Another example

    receive
       msg2 -> 42
    end




  • Waiting for multiple messages

    receive
       msg2 -> 42;
       _    -> 41
    end


    The _ matches with any message in the mailbox.



• The oldest message is tried against every pattern of the receive until one of them matches.

A simple echo-server

code

• Interaction

  • Process A sends a token to a Process B

  • Process B just returns it back to Process A

-module(echo).
-export([start/0, echo/0]).

echo() ->
  receive
    {From, Msg} ->
      From ! {self(), Msg},
      echo();
    stop ->
      true
  end.

start() ->
  Pid = spawn(fun echo/0),
  % sending tokens to the server
  Token = 42,
  Pid ! {self(), Token},
  io:format("Sent~w~n",[Token]),
  receive
    {Pid, Msg} ->
      io:format("Received ~w~n", [Msg])
  end,
  % stop server
  Pid ! stop.

• Observe that Process A waits only for a message from Process B ({Pid, Msg}, where Pid is bound)

• Servers are implemented using tail recursion

Client-Server Architecture

• Common asynchronous communication pattern

  • For example: a web server handles requests
    for web pages from clients (web browsers)



Mathematical server

code

• Off-loading heavy mathematical operations

  • For example: factorial

• Server code

   loop(Count) ->
       receive
          stop -> true ;

          {get_count, From, Ref} ->
                      From ! {result, Ref, Count},
                      loop(Count);

          {factorial, From, Ref, N} ->
                      Result = factorial(N),
                      From ! {result, Ref, Result},
                      loop(Count+1)
       end.

   % starting server with initial state 0
   start() -> spawn(fun() -> loop(0) end).


• Client code

  compute_factorial(Pid, N) ->
       Ref = make_ref(),
       Pid ! {factorial, self(), Ref, N},
       receive
           {result, Ref, Result} ->
                    Result
       end.


• A simple test

   > c(math_examples).
   {ok,math_examples}
   > math_examples:factorial(10).
   3628800
   > mserver:start().
   <0.40.0>
   > mserver:compute_factorial(list_to_pid("<0.40.0>"),10).
   3628800


• What if the server crashes or stop?

   > list_to_pid("<0.40.0>") ! stop
   > mserver:compute_factorial(list_to_pid("<0.40.0>"),10).
   * 2: syntax error before: mserver
   > mserver:start().
   <0.44.0>
   > mserver:compute_factorial(list_to_pid("<0.44.0>"),10).
   3628800


• Processes IDs are dynamic but code is static!

  • Change in a process ID might lead to notify all the potential clients

Sources of multiple messages

• Multiple messages can come from different processes (code)



  -module(echo2).
  -export([start/0, echo/1]).

  % New processes need to seed the random number generator
  % as all of them start with the same RNG state.
  echo(Seed) ->
    random:seed(Seed),
    echo().

  echo() ->
      receive
          {From, Msg} ->
              timer:sleep(random:uniform(100)),
              From ! {self(), Msg},
              echo();
          stop ->
              true
      end.

  start() ->
      SeedB = random:uniform(100),
      SeedC = random:uniform(100),
      PidB = spawn(echo2, echo, [SeedB]),
      PidC = spawn(echo2, echo, [SeedC]),

      % sending tokens
      Token = 42,
      PidB ! {self(), Token},
      io:format("Sent ~w~n",[Token]),
      Token2 = 7,
      PidC ! {self(), Token2},
      io:format("Sent ~w~n",[Token2]),

      % receive messages
      receive
         {PidB, Msg} ->
              io:format("Received from B: ~w~n", [Msg]) ;
         {PidC, Msg} ->
              io:format("Received from C: ~w~n", [Msg])
      end,

      receive
         {PidB, Msg2} ->
              io:format("Received from B: ~w~n", [Msg2]) ;
         {PidC, Msg2} ->
              io:format("Received from C: ~w~n", [Msg2])
      end,

      % stop echo-servers
      PidB ! stop,
      PidC ! stop.

  • Function timer:sleep(N) sleeps a process for N milliseconds

  • Function random:uniform(N) produces a random integer between 1 and N

  • Distinguish the source by Pids

• Multiple messages can come from the same processes (code)

  • Erlang has asynchronous messages

  • Send several messages of the same shape and continue computing

  • When receiving the responses, how can the code match them to the appropriate request?

     -module(echo3).
     -export([start/0]).

     echo() ->
         receive
             {From, Msg} ->
                 From ! {self(), Msg},
                 echo();
             stop ->
                 true
         end.

     start() ->
         PidB = spawn(fun echo/0),
         % sending tokens
         Token = 42,
         PidB ! {self(), Token},
         io:format("Sent~w~n",[Token]),
         Token2 = 41,
         PidB ! {self(), Token2},
         io:format("Sent~w~n",[Token2]),
         % receive messages
         receive
            {PidB, Msg} ->
                 io:format("Received 41? ~w~n", [Msg]) ;
            {PidB, Msg} ->
                 io:format("Received 42? ~w~n", [Msg])

         end,

         % stop echo-servers
         PidB ! stop.


  • BIF make_ref provides globally unique reference objects (references for short) different from every other object in the Erlang system including remote nodes

  • References can be used to uniquely identify messages! (code)

    -module(echo4).
    -export([start/0]).

    echo() ->
       receive
           {From, Ref, Msg} ->
               From ! {self(), Ref, Msg},
               echo();
           stop ->
               true
       end.

    start() ->
       PidB = spawn(fun echo/0),
       % sending tokens
       Token = 42,
       Ref = make_ref(),
       PidB ! {self(), Ref, Token},
       io:format("Sent~w~n",[Token]),
       Token2 = 41,
       Ref2 = make_ref(),
       PidB ! {self(), Token2},
       io:format("Sent~w~n",[Token2]),
       % receive messages
       receive
          {PidB, Ref2, Msg} ->
               io:format("Received 41? ~w~n", [Msg]) ;
          {PidB, Ref, Msg} ->
               io:format("Received 42? ~w~n", [Msg])

       end,

       % stop echo-servers
       PidB ! stop.


Registered processes

code

• Erlang has a method for publishing a process identifier

  • Any other process can communicate with it

• BIF register

   % starting server with initial state 0
   start() ->
       Pid = spawn(fun() -> loop(0) end),
       register(server,Pid).


• The atom server can be used instead of a concrete process ID

   > mserver2:start().
   true
   > mserver2:compute_factorial(server,10).
   3628800
   > server ! stop.
   stop
   > mserver2:compute_factorial(server,10).
   ** exception error: bad argument
        in function  mserver2:compute_factorial/2
   > mserver2:start().
   true
   > mserver2:compute_factorial(server,10).
   3628800


Distributed environments

• Message passing abstractions extend easily for distributed environments

• Erlang nodes

  • An instance of an Erlang runtime system

  • Nodes can easily communicate with each other

  • Creating a node

    erl -name 'nodeS@127.0.0.1' -setcookie lecture


    • The cookie provides security (not everyone can connect)
    • The name reflects the node's IP address

• Creating two nodes (for simplicity on the same machine)

  erl -name 'nodeS@127.0.0.1' -setcookie lecture
  erl -name 'nodeC@127.0.0.1' -setcookie lecture


• Connecting nodes

  • From nodeC@127.0.0.1

  (nodeC@127.0.0.1)> net_adm:ping('nodeS@127.0.0.1').
  pong
  (nodeC@127.0.0.1)> nodes().
  ['nodeS@127.0.0.1']


Distributed mathematical server

• Running your code

  • Send the compiled version of your code to the connected nodes

  (nodeC@127.0.0.1)> nl(math_examples).
  abcast
  (nodeC@127.0.0.1)> nl(mserver2).
  abcast


  • The server gets started on the nodeS node

  (nodeS@127.0.0.1)> mserver2:start().
  true


  • The client communicates with the server

  (nodeC@127.0.0.1)> mserver2:compute_factorial({server, 'nodeS@127.0.0.1'}, 10).
  3628800


  • Use of {registered_name, node@IP} instead of the process ID (e.g. <0.47.0>) or only the registered name (e.g. server)

  • The code has not been changed for running in a distributed setting!

Forking

• Spawning new process is also known as forking

• This terminology comes from the operating system community



• Look at the picture upside-down and you got a fork!

Message passing

• So far we considered synchronisation mechanisms based on shared variables

  • Concurrent programs require hardware in which processors share memory

• What about networked (distributed) architectures?

  • No shared memory

  • Message passing is the natural model for such scenarios

• Words by Joe Armstrong (Programming Erlang - Software for a concurrent world)

  The programming world went one way (toward shared state). The Erlang community went the other way. (Few other languages followed the “message passing concurrency” road. Others were Oz and Occam.)

  We don’t have shared memory. I have my memory. You have yours. We have two brains, one each. They are not joined together. To change your memory, I send you a message: I talk, or I wave my arms. You listen, you see, and your memory changes;

• It is relatively easy to adapt Erlang programs for distributed environments

How does it work?

• One process sends a message

• Another process awaits for a message

• Dimensions for message passing approaches:

  • What form of synchronisation is required

  • What form of process naming is involved in message passing

Forms of synchronization

Consider the behaviour of the sender of a message

• Asynchronous send

  • Send and continue working (e-mail, SMS)

• Synchronous send

  • Send and wait for the message to be received (fax)

• Rendezvous / Remote invocation

  • Send and wait for reply (phone call)

Examples

• Erlang has asynchronous message passing

• Ada has rendezvous

  • Previously used at Chalmers as a main teaching language

• Java has libraries

  • Sockets – asynchronous message passing

  • Remote Method Invocation – it can be seen as synchronous/rendezvous message passing

Forms of naming

How do sender and receiver refer to each other when message passing is used?

• Direct symmetric



• Direct asymmetric



  • Erlang has this naming convention
  • Sockets

• Indirect



  • Naming a process is not always convenient

  • Naming an intermediary can be more flexible

  • A channel, service name, or a mailbox

  • Potentially many-to-many communication

Erlang message passing

• Asynchronous send

• Receive from a mailbox



---

Exceptions

• Exceptions work similar as in Java

  1> (1/0) + 2.
  ** exception error: an error occurred when evaluating an arithmetic expression
       in operator  '/'/2
          called as 1 / 0


• Exceptions (errors) can be regarded as special values

• An error value poisons the computation

  (1/0) + 2
  →
  (error) + 2
  →
  (error)

• catch constructions limit the poisoning

  2> io:format("value: ~p~n", [1/0]).
  ** exception error: an error occurred when evaluating an arithmetic expression
       in operator  '/'/2
          called as 1 / 0


  io:format("value: ~p~n", [1/0])
  →
  io:format("value: ~p~n", [(error)])
  →
  io:format("value: ~p~n", (error))
  →
  (error)

  3> io:format("value: ~p~n", [catch (1/0)]).
  value: {'EXIT',{badarith,[{erlang,'/',[1,0],[]},

                        {erl_eval,do_apply,6,
                                  [{file,"erl_eval.erl"},{line,673}]},
                        {erl_eval,expr,5,[{file,"erl_eval.erl"},{line,431}]},
                        {erl_eval,expr,5,[{file,"erl_eval.erl"},{line,228}]},
                        {erl_eval,expr_list,6,
                                  [{file,"erl_eval.erl"},{line,877}]},
                        {erl_eval,expr,5,[{file,"erl_eval.erl"},{line,404}]},
                        {shell,exprs,7,[{file,"shell.erl"},{line,686}]},
                        {shell,eval_exprs,7,
                               [{file,"shell.erl"},{line,641}]}]}}
  ok


  io:format("value: ~p~n", [catch (1/0)])
  →
  io:format("value: ~p~n", [catch (error)])
  →
  io:format("value: ~p~n", [(error representation)])
  →
  io:format("value: ~p~n", [(error representation)])
  →
  ok

• catch exists in two variants

  • try ... catch ... after ... (like try-catch-finally in Java)
  • catch (simple version)

• Three constructions for errors exist

  • error() (default)
  • throw() (when the same code throws and catches exceptions used for flow-control)
  • exit() (typically used for exiting servers)

• One more kind of exceptions exists when process is killed — we will talk about it later

List comprehensions

1> [ X + 2 || X <- [2, 4, 5]].
[4,6,7]

2> [ X + Y * 10 || X <- [2, 4, 5], Y <- [1, 4]].
[12,42,14,44,15,45]

• List comprehensions contain one or more generators (X <- [2, 4, 5]), an expression (X + 2), and optionally filters

3> [ X + 2 || X <- [2, 4, 5], X > 3].
[6,7]

• Simple loops can be implemented using list comprehensions

4> [ io:format("~p~n", [X]) || X <- [apple, pear, orange]].
apple
pear
orange
[ok,ok,ok]

• Generators can depend only on (results of) earlier generators

5> [ {X, Y} || X <- [2, 3, 4], Y <- lists:seq(1, X)].
[{2,1},{2,2},{3,1},{3,2},{3,3},{4,1},{4,2},{4,3},{4,4}]

6> [ {X, Y} || Y <- lists:seq(1, X), X <- [2, 3, 4]].
* 1: variable 'X' is unbound

• Filters also can only refer to results of earlier generators

7> [ {X, Y} || X <- [2, 3, 4], Y <- lists:seq(1, X), Y > 1].
[{2,2},{3,2},{3,3},{4,2},{4,3},{4,4}]

8> [ {X, Y} || X <- [2, 3, 4], Y > 1, Y <- lists:seq(1, X)].
* 1: variable 'Y' is unbound

Lambda expressions

• Creating a new process requires defining a function

f() -> io:format("new process created!~n").

test() -> spawn(fun f/0).

• It is possible to define an anonymous function by using a lambda expression

f() -> io:format("new process created!~n").

test() -> spawn(fun () -> io:format("new process created!~n") end).

Higher-order functions

• Functions that take other functions as arguments (like spawn) are called higher-order functions (HOFs)

• HOFs are a very useful way of generalizing code

sum([])     -> 0;
sum([X|Xs]) -> X + sum(Xs).

mul([])     -> 1;
mul([X|Xs]) -> X * mul(Xs).

• Since the pattern of computation is the same for both sum and mul, we can create a common definition for both

reduce(_, E, [])     -> E;
reduce(F, E, [X|Xs]) -> F (X, reduce(F, E, Xs)).

sum2(L) -> reduce(fun(X, Y) -> X + Y end, 0, L).
mul2(L) -> reduce(fun(X, Y) -> X * Y end, 1, L).

• reduce/3 exists as lists:foldr/3

• We can also use reduce/3 to implement append/2 (concatenation of two lists)

append(L1, L2) -> reduce(fun(X, Y) -> [X|Y] end, L2, L1).

• Functions like sum and mul, where the binary operator is associative can be implemented using tail recursion efficienly

• append/2, on the other hand, cannot be

• For sum and mul one should use lists:foldl/3, which is tail-recursive

Begin-end blocks

• Begin-end blocks can be used to put a sequence of statements where comma means something else

f(a, b, begin io:format("hello~n"), c end)

---
